LZ1R-5.08-19P-140



       优势



  垂直型焊针,封闭型壳体,无安装螺丝；

  2-12P常备,最高可定制24P产品；

  通过防错插件对插头插座进行防错位保护。







Product Attribute
[Rated current(A)]	15A【UL】17.5A【IEC】
[Rated voltage(V)]	300V【UL】320【IEC】
[Insulation Resistance:]	PA/V0
[Poles(P):]	19p
[Terminal Block:]	pluggable terminal/PCB terminal block
[The same model]	MSTBA 2,5/19-G-5.08 MSTBA2.5/19-G-5.08 1757417 SL 5.08HC/19/180 3.2SN OR BX SL5.08HC/19/180 1147840000 SL 5.08HC/19/90G 3.2SN BK BX 1155510000 2EHDRC-19P 2EHDRC-19P 2EDGRC-5.08-19P-14 2EDGRC-5.08-19P OQ-5.08-19P-90D Close OQ1954510000G OQ-C/90D-5.08-19P 19POS 5.08MM CE R/A HDR, TRM BLK 19POS5.08MMCER/AHDR.TRMBLK 1-796638-9 1-796639-9 STLZ950/19G-5.08-H-绿色 50950195021D PTB750S-02-2-19-3 ME030-50819 F85-7-5.08-19P F857E1900051 PCB排针 8213 S / 19 W OB 8213S/19WOB 25.352.4953.0

Product Attribute
[Rated current(A)]	15A【UL】17.5A【IEC】
[Rated voltage(V)]	300V【UL】320【IEC】
[Insulation Resistance:]	PA/V0
[Poles(P):]	19p
[Terminal Block:]	pluggable terminal/PCB terminal block
[The same model]	MSTBA 2,5/19-G-5.08 MSTBA2.5/19-G-5.08 1757417 SL 5.08HC/19/180 3.2SN OR BX SL5.08HC/19/180 1147840000 SL 5.08HC/19/90G 3.2SN BK BX 1155510000 2EHDRC-19P 2EHDRC-19P 2EDGRC-5.08-19P-14 2EDGRC-5.08-19P OQ-5.08-19P-90D Close OQ1954510000G OQ-C/90D-5.08-19P 19POS 5.08MM CE R/A HDR, TRM BLK 19POS5.08MMCER/AHDR.TRMBLK 1-796638-9 1-796639-9 STLZ950/19G-5.08-H-绿色 50950195021D PTB750S-02-2-19-3 ME030-50819 F85-7-5.08-19P F857E1900051 PCB排针 8213 S / 19 W OB 8213S/19WOB 25.352.4953.0
