LZ1R-5.08-07P-140



       优势



  垂直型焊针,封闭型壳体,无安装螺丝；

  2-12P常备,最高可定制24P产品；

  接线容量大，可以连接截面积为2.5mm²的柔性导线；

  通过防错插件对插头插座进行防错位保护。







Product Attribute
[Rated current(A)]	15A【UL】17.5A【IEC】
[Rated voltage(V)]	300V【UL】320【IEC】
[Insulation Resistance:]	PA/V0
[Poles(P):]	7p
[Terminal Block:]	pluggable terminal/PCB terminal block
[The same model]	MSTBA 2,5/ 7-G-5.08 MSTBA2.5/7-G-5.08 1757297 SL 5.08HC/07/180 3.2SN OR BX SL5.08HC/07/180 1147420000 SL 5.08HC/07/90G 3.2SN BK BX 1155380000 2EHDRC-07P 2EHDRC-7P 2EDGRC-5.08-07P-14 2EDGRC-5.08-7P OQ-5.08-7P-90D Close OQ0754510000G OQ-C/90D-5.08-07P 7POS 5.08MM CE R/A HDR, TRM BLK 7POS5.08MMCER/AHDR.TRMBLK 796638-7 796639-7 STLZ950/7G-5.08-H-绿色 50950075021E PTB750S-02-2-07-3 ME030-50807 F85-7-5.08-07P F857E0700051 PCB排针 8213 S / 7 W OB 8213S/7WOB 25.352.3753.0

Product Attribute
[Rated current(A)]	15A【UL】17.5A【IEC】
[Rated voltage(V)]	300V【UL】320【IEC】
[Insulation Resistance:]	PA/V0
[Poles(P):]	7p
[Terminal Block:]	pluggable terminal/PCB terminal block
[The same model]	MSTBA 2,5/ 7-G-5.08 MSTBA2.5/7-G-5.08 1757297 SL 5.08HC/07/180 3.2SN OR BX SL5.08HC/07/180 1147420000 SL 5.08HC/07/90G 3.2SN BK BX 1155380000 2EHDRC-07P 2EHDRC-7P 2EDGRC-5.08-07P-14 2EDGRC-5.08-7P OQ-5.08-7P-90D Close OQ0754510000G OQ-C/90D-5.08-07P 7POS 5.08MM CE R/A HDR, TRM BLK 7POS5.08MMCER/AHDR.TRMBLK 796638-7 796639-7 STLZ950/7G-5.08-H-绿色 50950075021E PTB750S-02-2-07-3 ME030-50807 F85-7-5.08-07P F857E0700051 PCB排针 8213 S / 7 W OB 8213S/7WOB 25.352.3753.0
