LC2BM-5.08-12P-140



      优势



  插拔端子,集功用、价格优势于一身；

  可与多种插座匹配,应用范围广泛；

  接线容量大，可以连接截面积为2.5mm²的柔性导线；

  插头插座防错插防错位保护；



Product Attribute
[Rated voltage(V)]	320
[Rated current(A):]	17.5
[Rated current(mm²):]	2.5
[Wire Size(AWG):]	24-12
[Single/multi-core diameter(mm²):]	0.2-2.5
[Maximum locking torque(Nm):]	0.5-0.6
[Screw:]	M3
[Strip length(mm):]	7
[Resistant voltage(kv):]	4
[Insulation Resistance:]	PA/VO
[Poles(P):]	2-24
[Terminal Block:]	pluggable terminal PCB terminal block
[The same model]	MVSTBW 2.5/ ...STF BLZP 5.00HC/90F SN 5ESDPLM 2EDGKBM-5.0 TS5.0-D W/F MC211-E1 MVSTBW 2.5/ ...STF-5.08 BLZP 5.08HC/270F SN 2ESDPLM 2EDGKBM-5.08 TS5.08-D W/F MC211-F1

Product Attribute
[Rated voltage(V)]	320
[Rated current(A):]	17.5
[Rated current(mm²):]	2.5
[Wire Size(AWG):]	24-12
[Single/multi-core diameter(mm²):]	0.2-2.5
[Maximum locking torque(Nm):]	0.5-0.6
[Screw:]	M3
[Strip length(mm):]	7
[Resistant voltage(kv):]	4
[Insulation Resistance:]	PA/VO
[Poles(P):]	2-24
[Terminal Block:]	pluggable terminal PCB terminal block
[The same model]	MVSTBW 2.5/ ...STF BLZP 5.00HC/90F SN 5ESDPLM 2EDGKBM-5.0 TS5.0-D W/F MC211-E1 MVSTBW 2.5/ ...STF-5.08 BLZP 5.08HC/270F SN 2ESDPLM 2EDGKBM-5.08 TS5.08-D W/F MC211-F1
